TP-Link Archer AC1200 MU-MIMO VDSL/ADSL Wireless Modem Router, Black
TP-Link Archer AC1200 MU-MIMO VDSL/ADSL Wireless Modem Router, Black
Archer VR400 to deliver impressive VDSL broadband speeds of up to 100 Mbps—nearly 4 x faster than ADSL2+. Archer VR400 serves as a DSL modem and wireless router, combining two devices in one. Experience superb wireless connections with 867 mbps (5 ghz) + 300 mbps (2.4 ghz) dual band wifi. Superior range two fixed omnidirectional antennas with beamforming technology provide stable wireless connections and optimal coverage. Versatile connectivity fully compatible with vdsl2/adsl2+/adsl2/adsl standards, as well as fiber, cable and 3g/4g internet services. Whole-home coverage with one meshtm – works alongside tp-link onemeshtm products to create a flexible mesh network. Mu-mimo technology simultaneously transfers data to multiple devices, reducing wait times. Full gigabit ports take full advantage of broadband speeds up to 1 gbps. Tether app– tp-link tether provides the easiest way to access and manage your router on your ios and android devices.
| WAN connection |
| WAN connection type |
RJ-45 |
| 3G/4G USB modem compatibility |
No |
| SIM card slot |
No |
| DSL WAN |
Yes |
| Ethernet WAN |
Yes |
| Wireless LAN features |
| WLAN data transfer rate (second band) |
300 Mbit/s |
| WLAN data transfer rate (first band) |
867 Mbit/s |
| Wi-Fi standards |
802.11a |
| WLAN data transfer rate (max) |
867 Mbit/s |
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| Network |
| Number of guest networks (2.4 GHz) |
1 |
| Number of guest networks (5 GHz) |
1 |
| Dynamic DNS (DDNS) |
Yes |
| Port forwarding |
Yes |
| Port triggering |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Cabling technology |
10/100/1000Base-T(X) |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Ethernet LAN interface type |
Gigabit Ethernet |
| Ethernet LAN |
Yes |
| DSL features |
| VDSL2 |
Yes |
| ADSL2+ |
Yes |
| ADSL2 |
Yes |
| ADSL |
Yes |
| Ports & interfaces |
| RJ-11 ports quantity |
1 |
| USB 2.0 ports quantity |
1 |
| USB port |
Yes |
| Ethernet LAN (RJ-45) ports |
4 |
| Management features |
| MU-MIMO technology |
Yes |
| WPS push button |
Yes |
| Reset button |
Yes |
| Quality of Service (QoS) support |
Yes |
| Wi-Fi Multimedia (WMM)/(WME) |
Yes |
| Web-based management |
Yes |
| Security |
| Network address translation (NAT) |
Yes |
| DMZ support |
Yes |
| Filtering |
Yes |
| Parental control |
Yes |
| Guest access |
Yes |
| Firewall |
Yes |
| Security algorithms |
64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
| Protocols |
| Universal Plug and Play (UPnP) |
Yes |
| DHCP server |
Yes |
| DHCP client |
Yes |
| Design |
| Country of origin |
Malaysia |
| Product colour |
Black |
| Product type |
Tabletop router |
| General |
| Product family |
Archer |
| Packaging content |
| Packaging content |
1 x TP-Link Archer AC1200 MU-MIMO VDSL/ADSL Wireless Modem Router, Black |
| Quick installation guide |
Yes |
| AC adapter included |
Yes |
| Cables included |
LAN (RJ-45) |
| Antenna |
| Antennas quantity |
2 |
| Antenna design |
External |
| Features |
| Certification |
CE, RCM, RoHS |
| Power |
| Output current |
1 A |
| Output voltage |
12 V |
| Power source type |
DC |
| Weight & dimensions |
| Width |
215.6 mm |
| Depth |
124.6 mm |
| Height |
31.6 mm |
| Packaging data |
| Package weight |
580 g |
| Package height |
38 mm |
| Package depth |
266 mm |
| Package width |
124 mm |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
| Quantity per pack |
1 pc(s) |
