Origin Storage Inception TLC830 Pro Series 2TB M.2 (NGFF) 80mm SATA 3D TLC SSD
Inception TLC830 Pro Series 2TB M.2 (NGFF) 80mm SATA 3D TLC SSD
The Inception TLC830 Pro range of SSD Solutions are manufactured by Origin using the highest quality Tier 1 NAND and the latest generation of controllers which enables us to provide both high performance and strong reliability. All of our Inception SSDs come with 3 years advanced replacement warranty alongside free, in -house pre and post sales technical support. We can supply the TLC830 Pro in form factors of 2.5″, 3.5″ & M.2 with either SATA or NVME interfaces, whilst being available in a range of capacities designed to increase the performance & extend the lifecycle of any laptop or desktop.
| Features |
| Compatible products |
Universal |
| TBW rating |
800 |
| Backlight |
No |
| Linux operating systems supported |
Yes |
| Windows operating systems supported |
Yes |
| Mean time between failures (MTBF) |
1000000 h |
| Low-density parity-check (LDPC) |
Yes |
| Hot-swap |
No |
| ECC |
Yes |
| S.M.A.R.T. support |
Yes |
| Seek time |
0 ms |
| Access time |
0.2 ms |
| Sequential write speed (CDM) |
490 MB/s |
| Sequential read speed (CDM) |
530 MB/s |
| Sequential write speed (ATTO) |
470 MB/s |
| Sequential read speed (ATTO) |
540 MB/s |
| Random write (4KB) |
66560 IOPS |
| Random read (4KB) |
69120 IOPS |
| Write speed |
440 MB/s |
| Read speed |
510 MB/s |
| Data transfer rate |
6 Gbit/s |
| Hardware encryption |
No |
| Component for |
PC/Laptop |
| NVMe |
No |
| Memory type |
QLC 3D NAND |
| Interface |
Serial ATA III |
| SSD capacity |
2 TB |
| SSD form factor |
M.2 |
| Power |
| Power consumption (idle) |
0.54 W |
| Power consumption (write) |
4.55 W |
| Power consumption (read) |
3.1 W |
| Operating voltage |
3.3 V |
| Operational conditions |
| Vibration resistance |
15 G |
| Maximum operating altitude |
120000 m |
| Operating shock |
1500 G |
| Operating vibration |
16 G |
| Storage relative humidity (H-H) |
5 – 95% |
| Operating relative humidity (H-H) |
5 – 95% |
| Storage temperature (T-T) |
-55 – 95 °C |
| Operating temperature (T-T) |
0 – 75 °C |
| Technical details |
| Compliance certificates |
RoHS |
| Warranty period |
20 year(s) |
| Weight & dimensions |
| Weight |
5.6 g |
| Height |
1 mm |
| Depth |
80 mm |
| Width |
22 mm |
| Packaging data |
| Package type |
Blister |
| Screws included |
No |
| Storage drive adapter included |
No |
| Logistics data |
| Harmonized System (HS) code |
84717070 |
