Fractal Design Node 202 SFX HTPC Case, Mini ITX, Requires SFX PSU (Max 130mm), 310mm GPU Support, Horizontal/Vertical Orientation
This is the ultimate PC case for anyone looking for a beautifully designed, compact chassis that can house a capable gaming build
- Featuring a sleek and elegant design that will fit in any space or room
- Extremely small footprint with a volume of only 10.2 liters
- A highly versatile case that can be set up both vertically and horizontally
- Supports Mini-ITX motherboards, SFX power supplies and graphics cards up to 310mm in length
- Provides a smart thermal interior design highlighting separate motherboard and graphics card chambers
- Strategically placed air filters for a dust free interior
This small footprint is an intelligently built unit where extreme detail was placed into the design phase to get every line and spec in perfect harmony. With both horizontal and vertical orientation possibilities, the Node 202 can be placed anywhere in the house. The sleek design makes it very attractive next to the TV in the living room or on your desk in the office.
The internal layout of the Node 202 keeps the hot components separate and has them all placed in proximity of free-flow air so the case will run cool despite not having any extra case fans.
Description
Specification
- Form Factor: Mini ITX
- #Hide#Small Form Factor: Yes (SFF)
- Power Supply Wattage: No PSU
- Motherboard Support: Mini ITX
- #Hide#Window(s): No
-
Connectors / Controls: 2 x USB 3.0
Audio in/out
Power button with LED (white) - Drive Bays: 2 x 2.5″” (height limitation 10.5mm)
- Expansion Slots: 2 Expansion slots
-
Cooling System: Included
NoneFan Mounts
2 x 120 mm in graphics card chamber -
.:
Water Cooling options:
None - Colour: Black
-
Compatibility: GFX Card:
Max dimensions (LxHxD) 310 x 145 x 47 mmMax CPU Cooler:
56 mmPSU:
SFX (up to 130 mm long)
Not compatible with Ion SFX-L -
Weight/Dimensions: “3.5 kg
(W x H x D) 377 x 82 x 330 mm
Horizontal, w/ feet/protrusions/screws: 377 x 88 x 332 mm
Vertical, w/ feet/protrusions/screws: 125 x 385 x 332 mm
Volume: 10.3 litres” - Additional Features: See Overview / Video
-
Accessories: Accessory box
User manual
Vertical stand
Riser card for graphics card - Package Weight: 3.2000 kg
- Warranty: 2 Years
