Fractal Design Meshify 2 Compact (Black Solid) Gaming Case, ATX, Angular Mesh Front, 3 Fans, Detachable Front Filter, USB-C
Meshify 2 Compact is a high-performing case with a bold, stealth-inspired aesthetic. Its striking exterior features bolt-free, flush tempered glass, a fully removable top panel granting excellent interior access, and a front USB 3.1 Type-C port.
- Iconic angular mesh front provides filtered airflow with a bold, stealth-inspired aesthetic
- Room for GPUs up to 360 mm with a 240 mm radiator in the top, or up to 360/280 mm front radiators with GPUs under 305 mm
- Install up to 7x 120 mm or 4x 140 mm fans (1x 120 mm and 2x 140 mm Dynamic X2 fans included)
- Versatile and space-efficient ATX form-factor design offers the performance and capacity of much larger cases
- Open interior layout creates a smooth airflow path from front intake to rear exhaust
- Seamlessly integrated TG panel with steel frame support and bolt-free top-latching mechanism
- Fully removable top panel and top fan bracket opens to provide excellent interior access and easy cable routing
- Three front USB ports including one USB 3.1 Gen 2 Type-C with fast charging and speeds up to 10Gbps
- Robust cooling capacity with seven fan positions and support for up to 360/280 mm radiators
- Flexible storage options supporting two 2.5”/3.5” drives and up to four SSDs (two SSD brackets included)
- New front nylon filter that can be removed for increased airflow
- Easy-to-clean filters on the front, top and base with full PSU coverage and convenient front access
- Improved cable routing with three integrated cable alignment clips and six velcro straps
- Full length power supply shroud with two-part removable cover conceals drive cage and excess cabling for smooth airflow and a clean interior
- Seven bridgeless expansion slots ensure obstruction-free connections
Removable front filter
- New front panel design with hinged removable mesh and tether-free bezel for easier access to front fan mounts
- Easy-to-clean filters on the front, top and base with full PSU coverage and convenient front access
- New front nylon filter that can be removed for increased airflow
Robust cooling
- Install up to 7 fans, front radiators up to 360 mm, or top radiators up to 240 mm
- Open interior layout creates a smooth airflow path from intake to exhaust
- Install up to 7x 120 mm or 4x 140 mm fans (1x 120 mm and 2x 140 mm Dynamic X2 fans included)
Fully featured
- Seamlessly integrated steel panel with steel frame support and bolt-free top-latching mechanism
- Flexible storage options supporting two 2.5”/3.5” drives and up to four SSDs (two SSD brackets included)
- Improved cable routing with three integrated cable alignment clips and six velcro straps
Description
Specification
- Form Factor: ATX
- #Hide#Small Form Factor: No
- Power Supply Wattage: No PSU
- Motherboard Support: “ATX, Micro ATX, Mini ITX”
- #Hide#Window(s): No
-
Connectors / Controls: 1 x USB 3.1 Gen 2 Type-C
2 x USB 3.0
Audio I/O
Power button
Reset button -
Drive Bays: 2 x 3.5″”/2.5″”
4 x 2.5″” drive mounts (2 included) - Expansion Slots: 7 Expansion slots
-
Cooling System: Included
Front: 2 x Dynamic X2 GP-14 140mm fans
Rear: 1 x Dynamic X2 GP-12 120mm fanFan Mounts
Front: 3 x 120 / 2 x 140 mm
Top: 2 x 120 / 140 mm
Rear: 1 x 120
Bottom: 1 x 120 mm (requires removal of HDD cage) -
.:
Water Cooling options:
Front: Up to 360 / 280 mm radiator
Top: Up to 240 mm radiator
Rear: 120 mm radiator
Bottom: 120 mm radiator (requires removal of HDD cage) - Colour: Black
-
Material: Left side panel: Steel
Right side panel: Steel -
Compatibility: GPU max length:
341 mm (360 mm without front fan)CPU cooler max height:
169 mmPSU max length:
200 mm (165 mm with HDD cage and front fan) -
Weight/Dimensions: 7.7 kg
(LxWxH) 424 x 210 x 475 mm
w/o feet/protrusions/screws: 412 x 210 x 455 mm - Additional Features: See Overview / Video
-
Accessories: User manual
Accessory box - Package Weight: 9.6500 kg
- Warranty: 2 Years
