Cooler Master MasterBox NR200P V2 Case w/ Glass or Mesh Side, Mini ITX, Requires SFX/SFX-L PSU, 1x Fan, USB-C, 356mm GPU & 280mm Radiator Support, White
Compact yet powerful
- Stay cool under pressure
- Optimized GPU performance
- Comprehensive GPU support
- Easy, tool-free access
- USB 3.2 Gen 2×2 Type C support
- Refreshed NCORE style
Build Small. Play Big.
This case is compatible with SFF-Ready Enthusiast GeForce cards, so you can pack high performance into a smaller footprint. Look for SFF-Ready Enthusiast GeForce Cards to get a sure fit and streamline your PC build.
Stay cool under pressure
No performance compromises with support for 240mm/280mm liquid coolers, providing the ultimate in thermal efficiency.
Compact yet powerful
An ultra-sleek 18.25L design delivers unmatched performance and aesthetics with vented steel and tempered glass side panels.
Optimized GPU Performance
An efficient vertical airflow layout supported by a 120mm bottom-mounted fan keeps your GPU extra cool.
Comprehensive GPU Support
Includes vertical mounting options, a custom PCle 4.0 riser cable, and a support bracket for GPUs up to 356mm in length and 160mm in height.
USB 3.2 gen 2×2 Type C support
A USB 3.2 Gen 2×2 Type C port is built into the 1/0 panel with up to 20Gbps transfer speeds.
Easy, Tool-Free Access
All external panels are secured with pins for easy removal, facilitating quick access to the internals without the use of tools while a removable GPU panel simplified the installation process.
The New NCORE Style
An NCORE redesign provides a sleek take on maximizing cooling performance and style simultaneously.
Description
Specification
- Form Factor: Mini ITX
- #Hide#Small Form Factor: No
- Power Supply Wattage: No PSU
- Motherboard Support: Mini ITX (Max 170 x180mm)
- #Hide#Window(s): Yes (Window)
-
Connectors / Controls: 1x USB 3.2 Gen 2×2 Type-C
2 x USB 3.2 Gen 1 Type-A
1 x 3.5mm Headset Jack (Audio+Mic) -
Drive Bays: “1 x 3.5″” Drive Bays (Max. 2, remove bottom fan)
1 x 2.5″” / 3.5″” Drive Bays (Combo)
1 x 2.5″” Drive Bays (Max. 2)” - Expansion Slots: 3 Expansion Slots
-
Cooling System: “Included:
Bottom: 1 x 120mm PWM SickleFlow fanFan Mounts:
Top: 2 x 120/ 2 x 140mm
Bottom: 2 x 120mm (1x max 15mm, w/o 3.5″” HDD at the bottom)” -
.:
Radiator Options:
Top: 240/280 mm - Colour: White
-
Material: “Exterior: SGCC Steel, Mesh, ABS Plastic
Left Side: Tempered Glass or Steel Mesh (both included)” -
Compatibility: “GPU Clearance:
Exceed front bracket: L: 357mm (incl. power connector) , H: 160mm (incl. power connector) , W: 73mm (triple slot)
Not exceed front bracket: L: 334mm (incl. power connector) , H: 160mm (incl. power connector) , W: 80mm (triple slot)CPU Clearance:
67 mmPSU Clearance:
SFX, SFX-L required
130 mm” -
Weight/Dimensions: (LxWxH) 372 x 185 x 292 mm (Incl. Protrusions)
(LxWxH) 360 x 185 x 274 mm (Excl. Protrusions)
Volume: 18.25L -
Additional Features: “New NCORE Style Redesign
Easy, Tool-Free Access
Dust Filters: Bottom, Left, Right, Top Panels
Both Tempered Glass & Steel Mesh Side Panel IncludedSee Overview for more details”
-
Accessories: 1 x PCIe 4.0 x16 riser cable
1 x GPU Holder - Package Weight: 6.6000 kg
- Warranty: 2 Years
